Section 10. Electrical System
10-65 Model 6036/6036T S/N 9B0500 thru 14833
Trouble Probable Cause Remedy Reference
Switches and Solenoids—REVERSE SWITCH AND BACKUP ALARM
Backup alarm
doesn’t sound
with travel select
lever in REVERSE. 1. No voltage at backup
alarm; broken wire or
circuit breaker (11) doesn’t
reset.
2. Defective reverse switch.
Replace wiring and circuit
breaker as required.
Replace reverse switch.
See para. 10.4
See para. 10.7.5
Switches and Solenoids—STEERING SELECT SWITCH AND SOLENOID
Steering select
switch fails to
select mode or
selects incorrect
steering mode. 1. Short circuit or broken
wire.
2. Circuit breaker stuck in
open position.
3. Steering select switch is
defective.
4. Steering select solenoid is
defective.
Eliminate short or repair or
replace wire.
Replace circuit breaker.
Remove steering select
switch and check for
continuity in each position and
replace switch if defective.
Remove steering select
solenoid and test for correct
operation.
See para. 10.7.6
See para. 10.4
See para. 10.7.6
See para. 10.7.7
Gauges and Indicator Lights—HOURMETER
Hourmeter
Doesn’t
Operate. 1. Defective wiring and
ground.
2. Incorrect voltage at meter
terminals.
Renew wiring and correct
ground.
Required voltage is 9 to
36 Vdc.
See para. 10.8.3
See para. 10.8.3
Backup alarm
sounds with travel
select lever in
NEUTRAL AND
FORWARD 1. Short circuit in wiring.
2. Defective reverse switch.
Determine and repair cause of
short circuit.
Test and replace reverse
switch as required.
See para. 10.2.2
See para. 10.7.5
Hourmeter is
Inaccurate. Check running indicator flag
wheel. Replace hourmeter if
defective. See para. 10.8.3
