Section 9 Hydraulic System
Model 6036/6036T S/N 9B0500 thru 14833 9-71
Fig. 9.40 Main Control Valve Exploded View
3
21
19
22
23
21 17
5
5
6
7
10
8
9
15
11
12
11
18
20 2
22
6
7
5
13
14
15
16
18
13
14
4
MA4010
1. Inlet Section
2. Outlet Section
3. Boom Raise/Lower Section
4. Boom Extend/Retract Section
5. O-ring
6. Check Valve Poppet
7. Check Valve Spring
8. Socket Head Capscrew (2)
9. Spool Cap
10. Spool End
11. Spring Seat (2)
12. Spring
13. Wiper (2)
14. O-ring (2)
15. Seal Plate (2)
16. Round Head Machine Screw (2)
17. Main Relief Valve
18. Port Relief Valve (3)
19. Tie Rod (2)
20. Tie Rod (1)
21. Special Nut (4)
22. Special Nut (2)
23. Plug Assembly
24. Plug
25. O-ring
KITS
See Parts Manual
18
24
25
1
