SkyTrak 6036 Service Manual - Manual (Page 271)

Section 10. Electrical System
Model 6036/6036T S/N 9B0500 thru 14833 10-9
Fig. 10.7 Drawing 2 Engine Harness and Components of Electrical System - Perkins Engine Only
PA1093
W
B+
D+
WIRE #5
WIRE #6
WIRE #38
ALTERNATOR AS VIEWED
FROM BACKSIDE
WIRE #2
(-)
(+)
(-)
(+)
34 2 16
20 25
31
1
17
14
34
36
27
S I
31
5
6
38
15
44
19
29
27
36
5
18
44
14
37
29
37
19
21
17
35
20
38
18
25
6
16
15
2
NOT
USED
NOT USED
STARTER
SOLENOID
FUEL
TANK
NOT USED
WIRING CONFIGURATION
DELCO
(EARLIER PRODUCTION)
35 1
2
31
2
WIRING CONFIGURATION
BOSCH ALTERNATOR
(CURRENT PRODUCTION)
6 38 5 2
41. Lockwasher, M5
42. Nut, Hex, M8
43. Harness, Engine
44. Battery, 12 Volt
45. Cable, Battery-Negative
46. Cable, Starter Ground (Not Shown)
47. Cable, Battery-Positive
48. Screw, Washer Hd, Type B, 3/8 x 3/4
49. Horn
50. Backup Alarm
51. Screw, Hex Hd Cap, 1/4-20 x 1-1/4 Gr 5
52. Nut, Hex, 1/4-20
53. Lockwasher, 1/4
54. Switch, Transmission Temperature
55. Sender, Low Oil Pressure 56. Sender, Water Temperature
57. Solenoid, Fuel Run
58. Switch, Neutral Start
59. Relay, Starter
60. Starter
61. Solenoid, Starter
62. Alternator
63. Sender, Fuel Level
64. Wire Assembly
65. Plug, Thermo Start
66. Screw, Round Hd Machine, #8-32 x 1/4
67. Tie Wrap (Not Shown)
68. Nut, Jam, M10
69. Lockwasher, M8
49
50
51
52
53
54
55
56
43
44
57
58
59
60
45
46
47
48
60
61
62
63
64
65
66
68,69
62
41,42
41,42
