4-16
Agilent E5250A User’s Guide, Edition 11
Setting up Measurement Environment
Connecting the E5250A Input
Table 4-3
E5250A Input Connections
Application
Instrument
E5250A
Input
Connector
Cable Required
Agilent
Model No.
Output
Connector
DC
Measurement
4155
MPSMU
SMU1 to 6
16494A-003 Triaxial cable
VSU
AUX1 to 4
BNC cable
VMU
AUX1 to 4
BNC cable
Intlk
−
16493J Interlock cable
(for direct connection to Connector Plate)
4156
HRSMU
SMU1 to 6
16494B-003 Kelvin Triaxial cable or
16494A-003 Triaxial cable
VSU
AUX1 to 4
BNC cable
VMU
AUX1 to 4
BNC cable
Intlk
−
16493J Interlock cable
(for direct connection to Connector Plate)
41501
HPSMU
SMU1 to 6
16494B-003 Kelvin Triaxial cable or
16494A-003 Triaxial cable
MPSMU
SMU1 to 6
16494A-003 Triaxial cable
PGU
HF1 or 2
BNC cable
GNDU
SMU1 to 6
16493H GNDU cable
and E5250-60004 Adapter
−
16493H GNDU cable
(for direct connection to Connector Plate)
4142B
SMU
SMU1 to 6
16494C-001 Kelvin Triaxial cable or
16494A-001 Triaxial cable
VSU
AUX1 to 4
BNC cable
VMU
AUX1 to 4
BNC cable
GNDU
SMU1 to 6
16493H GNDU cable
and E5250-60044 Adapter
−
16493H GNDU cable
(for direct connection to Connector Plate)
Intlk
−
16435A Interlock cable adapter
and 16493J Interlock cable
(for direct connection to Connector Plate)
