Agilent E5250A User’s Guide, Edition 11

5-37

Controlling the E5250A

Using Virtual Front Panel Utility

Figure 5-13

Memory Setup Panel for the E5255A in Normal Config. (2 X 24 multiplexer)

Agilent E5250A Virtual Front Panel Utility

** MEMORY SETUP PANEL **

Current Setup Memory : 1

Comment

: MOS CAP

Card Number

: 1

Input

12345678

IV1 @.......

BS1 *

.@@@@@@@

IV1 ........

BS1 *

@@@@@@@@

IV1 ........

BS1 *

--------

Use softkeys to move cursor and to change status.

Figure 5-14

Memory Setup Panel for the E5255A in Auto Config. (2 X 24 multiplexer)

Agilent E5250A Virtual Front Panel Utility

** MEMORY SETUP PANEL **

Current Setup Memory : 1

Comment

: MOS CAP

Card Number

: 0

111111111122222

Input 123456789012345678901234

IV1 @.......................

BS1 *

.@@@@@@@@@@@@@@@--------

Use softkeys to move cursor and to change status.
