5-38 Agilent E5250A User’s Guide, Edition 11
Controlling the E5250A
Using Virtual Front Panel Utility
You can define labels to use for the input ports of each row in the MEMORY
SETUP PANEL. Refer to “Defining Labels for the E5250A Input Ports” on page
5-31.
The following softkeys are displayed for MEMORY SETUP PANEL:
Softkey Description
CHANGE
CHAN For changing the settings in the Current Setup Memory. See
later. Displays cursor for input-output crosspoints and some
softkeys.
COMMENT For entering a comment for the setup memory. See next page.
NEXT
CARD (Displayed only for NORMAL Config mode, not AUTO Config
mode.) Displays MEMORY SETUP PANEL of next card for
changing settings.
SWITCH
PAGE (Displayed only for AUTO Config mode, not NORMAL Config
mode.) Displays other page of MEMORY SETUP PANEL if
more than 48 output ports. This softkey is displayed if the
E5250A is configured for multiplexer that has more than 48
outputs (example, 2
×96 multiplexer). This softkey toggles
between the MEMORY SETUP PANEL for outputs 1 to 48, and
for 49 to 96.
NEXT
SETUP Changes the Current Setup Memory to next setup memory
number. Increases the Current Setup Memory number by 1. And
changes the E5250A to the new settings.
PREV
SETUP Changes the Current Setup Memory to previous setup memory
number. Decreases the Current Setup Memory number by 1. And
changes the E5250A to the new settings.
GOTO
SETUP For changing the E5250A to settings of specified setup memory.
See later. Changes Current Setup Memory to specified setup
memory number.
SETUP
MEMORY Returns to the SETUP MEMORY MENU.
