5-32 Agilent E5250A User’s Guide, Edition 11
Controlling the E5250A
Using Virtual Front Panel Utility
To define labels for the E5255A bias input ports
Select the CARDn INPUT softkey (n=1 to 4). The following softkeys are displayed:
Select the BIASn LABEL softkey (n=1 to 3). The following message is displayed:
Input Label Name. (Max 5 char string)
Type desired label (maximum 5 characters), then press the Enter key.
If you press the Enter key without typing any characters, the label is cleared.
Figure 5-10 Example of DEFINE LABEL MENU
Agilent E5250A Virtual Front Panel Utility
** DEFINE LABEL MENU **
E5250A INPUT1 : " IV1 "
INPUT2 : " IV2 "
INPUT3 : " IV3 "
INPUT4 : " IV4 "
INPUT5 : " IV5 "
INPUT6 : " IV6 "
INPUT7 : " HF1 "
INPUT8 : " HF2 "
INPUT9 : " CV1 "
INPUT10 : " CV2 "
CARD1 E5252A No Bias Input Port
CARD2 E5252A No Bias Input Port
CARD3 E5255A BIAS1:"C3B1 " BIAS2:"C3B2 " BIAS3:"C3B3"
CARD4 E5255A BIAS1:"C4B1 " BIAS2:"C4B2 " BIAS3:"C4B3"
Select desired softkey.
Softkey Description
BIASn
LABEL
(n=1 to 3) For selecting input Bias Port on the E5255A that was selected by
the CARDn INPUT softkey. See below.
RETURN For returning to the DEFINE LABEL MENU.
