10-4
Agilent E5250A User’s Guide, Edition 11
Specifications
Option 001 Matrix Switch
Option 001 Matrix Switch
Switch Specifications
This specification is defined with the module plugged into the mainframe. The value
depends on the following temperature and humidity conditions.
•
A: 23
°C ± 5 °C, 5 % to 60 % RH
•
B: 5
°C to 18 °C, 28 °C to 40 °C, 5 % to 60 % RH
•
C: 28
°C to 40 °C, 60 % to 80 % RH
A B C
Max. Current Rating (A)
1.0
1.0
1.0
Max. Voltage Rating (V)
Channel to Guard
200
200
200
Channel to Channel
300
300
300
Closed Channel Residual Resistance (
Ω)
Low Leakage I-V Port
0.6
0.6
0.6
General I-V Port
1.0
1.0
1.0
C-V Port, HF Port
1.0
1.0
1.0
Channel Isolation Resistance (
Ω)
Low Leakage I-V Port
10
13
5
Ч 10
12
2
Ч 10
12
General I-V Port
10
12
5
Ч 10
11
2
Ч 10
11
C-V Port, HF Port
10
9
5
Ч 10
8
2
Ч 10
8
