9-12 Agilent E5250A User’s Guide, Edition 11
Executing Sample Programs
Vth and Capacitance Measurement Program
To output the measurement report to printer
You can EDIT to change the following parameters in the Init_setting
subprogram. Printer must be connected to computer by using GPIB cable. The
report as shown in example in Figure 9-2 will be printed automatically.
To execute the 4155/4156 calibration
Remove the exclamation marks from program lines shown below, and enter the
lines. These lines are in Init_instrument subprogram. The calibration will be
done automatically before measurement.
! CALL Cal415x
! DISP "Agilent 4155/4156 Calibration Completed"
To save the 4155/4156 measurement data
To save the Vth measurement data to a diskette in the 4155/4156's disk drive,
remove the exclamation marks from the program lines shown below, and enter the
lines. These lines are in the "Save Measurement Data" block of the Meas_vth
subprogram.
! OUTPUT @Hp415x;":MMEM:STOR:TRAC DEF,'VTH.DAT','DISK'"
! OUTPUT @Hp415x;"*OPC?"
! ENTER @Hp415x;A
The measurement data will be saved to the VTH.DAT file after the measurement. If
desired, you can use another file name instead of VTH.DAT.
Parameter Description Default
Ad_prn GPIB address for printer 1
Prn_enab Enable/disables print out function.
(1: Enable, 0: Disable) 0
