9-22
Agilent E5250A User’s Guide, Edition 11
Executing Sample Programs
HCI Measurement Program
The measurement data is saved to the diskette in disk drive connected to the
computer with the following file names.
•
IDXX: Percent change data for Idlin
•
GMXX: Percent change data for Gmmax
•
VTEXX: Relative shift data for Vtext
•
VTIXX: Relative shift data for Vtci
where XX means the test device number.
Required Equipments
Prepare the equipment shown in Table 9-6, which lists the required equipment to
execute the program:
Table 9-6
Required Equipment
Agilent Model/Part No.
Description
Qty.
E5250A
Low Leakage Switch Mainframe
1
E5255A
24 (8
×3) Channel Multiplexer
3
4155/4156
Semiconductor Parameter Analyzer
1
41501
SMU/PGU expander (for GNDU)
1
16494A-001 or -002
Triaxial Cable (1.5 m or 3 m)
1
16494A-003
Triaxial Cable (80 cm)
3
16494D-001 or -002
8 Channel Shielded Coaxial Cable (1.5 m or 3 m)
9
16495D
Connector Plate
1
10833A/B/C
GPIB Cable
5
E5250-17002
E5250A Program Disk (furnished)
1
−
Bias Source
3
−
BNC - BNC cable (for Bias Source)
3
−
3.5 inch diskette (for storing measurement data
and modified program)
1
