3-18 Agilent E5250A User’s Guide, Edition 11
Executing Self-Test and Leak Test
Using the Self-Test Utility
5. Select the desired SMUm softkey (m=1 to 6). Following message is displayed
depending on the connection type:
• Message for Kelvin connection:
Disconnect Kelvin cable from IVn terminal.
And disconnect all cables from output terminals.
• Message for non-Kelvin connection:
Disconnect cable from IVn terminal.
And disconnect all cables from output terminals.
Where n=1 to 6. And the following softkeys are displayed.
6. Disconnect all cables from the E5250A input/output terminals. Then connect
triaxial cable or Kelvin triaxial cable to the 4155/4156 SMU terminal you
specified in step 5 because the next step executes the zero offset cancel.
7. Select the CONTINUE softkey. The following message is displayed depending
on the connection type:
• Message for Kelvin connection:
Connect SMUm to IVn by Kelvin cable.
• Message for non-Kelvin connection:
Connect SMUm to IVn by cable.
Where m=1 to 6 (specified by SMUm softkey) and n=1 to 6 (specified by IVn
softkey).
And the following softkeys are displayed.
Softkey Description
CONTINUE To continue setting up the Leak Test.
CANCEL Cancels the Leak Test execution.
Softkey Description
CONTINUE Executes the Leak Test. Consecutively connects input port
specified by IVn softkey to each output port and makes
leak measurement.
CANCEL Cancels the Leak Test execution.
