6-12 Agilent E5250A User’s Guide, Edition 11
Programming the E5250A
Creating a Control Program
Controlling Relay Switching
Following commands are used to control relay switching. For details of
channel_list, see “Channel List and Channel Configuration” on page 5-6.
Example: 100 OUTPUT @Hp5250;":ROUT:CLOS (@10101,10202)"
110 ! Closes relays to create channels 10101 and 10202.
Command Description
:ROUT:CLOS channel_list Close the relays specified by channel_list.
:ROUT:OPEN channel_list Open the relays specified by channel_list.
:ROUT:OPEN:CARD card_no Open all relays on card specified by card_no.
