System Control Register 2 (SYSCON2)
Address:
0x8000.1100, Read / Write
Definition:
The SYSCON2 system control register is a 15-bit read/write register
which controls some of the general configuration parameters for the
EP73xx as well as the control and status of internal peripherals. All
bits in this register are cleared upon system reset (nSYSRES).
Bit Descriptions:
SERSEL:
SSI2/CODEC select. When this bit is cleared, SSI2 is connected to
the external pins. When it is set, the CODEC interface is
connected. The value of this bit is overridden when the DAISEL
bit of SYSCON3 is set, attaching the DAI to the pins.
KBD6:
The state of this bit determines how many of the Port A inputs are
OR’ed together to create the keyboard interrupt. When zero (the
reset state), all eight of the Port A inputs will generate a keyboard
interrupt. When set high, only Port A bits 0 to 5 will generate an
interrupt from the keyboard. It is assumed that the keyboard row
lines are connected into Port A.
SDRAMZ: The bit determines the width of the SDRAM memory interface,
where: 0=32-bit SDRAM and 1=16-bit SDRAM.
KBWEN:
When set, the CPU will wake from the STANDBY or IDLE states
upon the assertion of a signal on any of the Port A inputs.
Enabling this feature will allow the CPU to wake up regardless of
the state of the KBDINT interrupt mask (INTMR2 bit 0).
SS2TXEN: Transmit enable for the synchronous serial interface 2. The
transmit side of SSI2 will be disabled until this bit is set. When set
low, this bit also disables the
SSICLK
pin (to save power) in master
mode, if the receive side is low.
SS2RXEN: Receive enable for the synchronous serial interface 2. The receive
side of SSI2 will be disabled until this bit is set. When both
SSI2TXEN and SSI2RXEN are disabled, the SSI2 interface will be
in a power saving state.
UART2EN: Internal UART2 enable bit. Setting this bit enables the internal
UART2.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
BUZFRE
Q
CLKEN
SL
OSTB
RSVD
SS2MA
EN
UART2E
N
SS2RXE
N
RSVD
SS2TXE
N
KBWEN
SDRAM
Z
KBD6
SERSEL
