4-8

EP7309/11/12 User’s Manual - DS508UM4



Copyright Cirrus Logic, Inc. 2003

Interrupt Controller

Interrupt Register Descriptions

Interrupt Status Register 1

(INTSR1)

Address:

0x8000.0240, Read Only

Definition:

The interrupt status register is a 32-bit read only register. The
interrupt status register reflects the current state of the first 16
interrupt sources within the EP73xx. Each bit is set if the appropriate
interrupt is active. The interrupt assignment is given below.

Bit Descriptions:

RSVD:

Unknown during Read.

EXTFIQ:

External fast interrupt. This interrupt will be active if the

nEXTFIQ

input pin is forced low and is mapped to the FIQ input on the
ARM720T processor.

BLINT:

Battery low interrupt. This interrupt will be active if no external
supply is present (

nEXTPWR

is high) and the battery OK input pin

BATOK

is forced low. This interrupt is de-glitched with a 16 kHz

clock, so it will only generate an interrupt if it is active for longer
than 125

µs. It is mapped to the FIQ input on the ARM720T

processor and is cleared by writing to the BLEOI location. BLINT
is disabled during The Standby State.

WEINT:

Tick Watch dog expired interrupt. This interrupt will become
active on a rising edge of the periodic 64 Hz tick interrupt clock if
the tick interrupt is still active (i.e., if a tick interrupt has not been
serviced for a complete tick period). It is mapped to the FIQ input
on the ARM720T processor and the TEOI location.

Note: WEINT and watchdog timer are disabled during the Standby State. The watch

dog timer tick rate is 64 Hz (in 13 MHz and 73.728–18.432 MHz modes).

RSVD

SSEOTI

UMSINT

URXINT1

UTXINT1

TINT

RTCMI

TC2OI

TC1OI

EINT3

EINT2

EINT1

CSINT

MCINT

WEINT

BLINT

EXTFIQ
