DAI Control Register (DAIR)
Address:
0x8000.2000, Read / Write
Bit Descriptions:
(See full bit descriptions for complete details)
[0:15]:
Reserved. Must be set to 0x0404
DAIEN:
DAI Interface Enable (See additional notes for more detail)
0-DAI operation disabled. Control of SDIN,SDOUT,SCLK and
LRCLK given to the SSI2/CODEC/DAI multiplexor to assign
pins to another block
1-DAI operation enable.
Note: The SSI/CODEC by default have precedence of the DAI interface in regards to
the use of the I/O pins.
ECS:
1=for 64 Fs mode. Bit is ignored in 128 Fs mode.
LCTM:
Left Channel Transmit FIFO Interrupt Mask.
0=Left Channel Transmit FIFO half-full or less condition does not
generate and interrupt. LCTS is ignored
1=Left Channel Transmit FIFO half-full or less condition does
generate and interrupt. LCTS status sent to interrupt controller
LCRM:
Left Channel Receive FIFO Interrupt Mask.
0=Left Channel Receive FIFO half-full or less condition does not
generate and interrupt. LCTS is ignored
1=Left Channel Receive FIFO half-full or less condition does
generate and interrupt. LCTS status sent to interrupt controller.
RCTM:
Right Channel Transmit FIFO Interrupt Mask.
0=RightChannel Transmit FIFO half-full or less condition does not
generate and interrupt. RCTS is ignored
1=Right Channel Transmit FIFO half-full or less condition does
generate and interrupt. RCTS status sent to interrupt controller
RCRM:
Right Channel Receive FIFO Interrupt Mask.
0=Right Channel Receive FIFO half-full or less condition does not
generate and interrupt. RCTS is ignored
1=Right Channel Receive FIFO half-full or less condition does
generate and interrupt. RCTS status sent to interrupt controller.
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
RCRM
RCTM
LCRM
LCTM
RSRVD
ECS
DAIEN
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
