4-12
EP7309/11/12 User’s Manual - DS508UM4
Copyright Cirrus Logic, Inc. 2003
Interrupt Controller
4
URXINT2: UART2 receive FIFO half full interrupt. The function of this
interrupt source depends on whether the UART2 FIFO is enabled.
If the FIFO is disabled, this interrupt will be active when there is
valid RX data in the UART2 RX data holding register and be
cleared by reading this data. If the FIFO is enabled, this interrupt
will be active when the UART2 RX FIFO is half or more full or if
the FIFO is non-empty, and no more characters have been received
for a three-character time-out period, it is cleared by reading all
the data from the RX FIFO. The FIFO is 16 bytes deep.
Interrupt Mask Register 2 (INTMR2)
Address:
0x8000.1280, Read / Write
Definition:
This register is an extension of INTMR1, containing the interrupt
mask bits. All of the interrupts represented in INTMR2 trigger the
standard interrupt (IRQ) signal of the ARM720T core. Please refer to
INTSR2 for individual bit details.
Descriptions:
(See
“Interrupt Status Register 2 (INTSR2)”
for details)
Interrupt Status Register 3
(INTSR3)
Address:
0x8000.2240, Read / Write
Definition:
This register is an extension of INTSR1 and INTSR2 containing only
the status bit for the DAI interface of the EP73xx. Each bit is set if the
appropriate interrupt is active. The interrupt assignment is given
below.
Bit Descriptions:
RSVD:
Unknown during Read.
DAIINT:
DAI interface interrupt. The cause must be determined by reading
the DAI status register. It is mapped to the FIQ interrupt on the
ARM720T processor
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
URXINT2
UTXINT2
RSVD
SS2TX
SS2RX
KBDINT
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
RSVD
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RSVD
DAIINT
