UART and SIR Encoder
1717
17
UART1
UART 1 supports three modem control signals CTS, DTS, and DCD. The additional RI
input, RTS and DTS output modem control lines are not explicitly supported but can
be implemented by using GPIO pins. UART1 is enabled in SYSCON1 at UART1EN
(bit 8).
Programming the UART configuration is done via the UBRLCR1-2 register.The input
and output register where data is sent and received from the FIFOs can be accessed
via the UART1-2 data (holding) register.
Three interrupts can be generated by UART1: Rx, Tx, and modem status interrupts.
The Rx interrupt is generated when the FIFO (if enabled) is half-full, or is non-empty
for longer than three character length times with no more characters being received. If
the FIFOs are not enabled, the interrupt can occur when there is data in the UART1
holding register. The transmit interrupt can occur if the internal transmit FIFO (if
Table 17-3: UART Bit Rate in PLL Clock Mode (74 MHz)
Divisor Value
Bit Rate Running from
the PLL Clock
0
—
1
115200
2
76800
3
57600
5
38400
11
19200
15
14400
23
9600
95
2400
191
1200
2094
110
Table 17-4: UART Bit Rate from 13 MHz Clock
Divisor Value
Bit Rate Running from
13 MHz Clock
Error on
13 MHz Value
0
116071
0.75%
1
58036
0.75%
2
36890
0.75%
5
19345
0.75%
7
9673
0.75%
47
2416
0.42%
96
1196
0.28%
1054
110.02
0.18%
