4. Control panel (only type SFC−LACI−...−H2)
4−10
Festo P.BE−GDCP−SFC−LACI−PB−E N en 0812NH
[Diagnostic] [...] Description
[PROFIBUS Diag] ConState Configuration status
Ĉ WaitPrm: Wait for parameterising
Ĉ WaitCfg:
Waiting for configuration
Ĉ DataEx: Data exchange
Baud rate Current baud rate
MasterAdr Address of the master
SlaveAdr Address of the SFC−LACI
ActCFG Pre−set data profile.
Current bus configuration.
Ĉ Invalid:
No or incorrect configuration by master
(e.g. by invalid GSD file)
Ĉ FHPP Std.:
Control via control bytes
Ĉ FHPP FPC:
Controlled via control bytes, parameterising via the
Festo parameter channel
GbDiagnose Device related diagnosis ON/OFF
[SW information] SFC−LACI firmware version
Tab. 4/3: [Diagnostic] menu
