B.3.3 Representation of the parameter entries
Encoder resolution
PNU 1001 1 ... 2 0 ... 1 uint32 rw
Description Encoder resolution in increments / revolutions
The encoder resolution is fixed and cannot be modified by the
user. The calculated value is derived from the fraction
(encoder increments/motor revolution).
Encoder
Increments
1001 1 0
Increments
(encoder
increments)
Value range: 0 ... 2 32 − 1
Default: 500
Motor Revolutions
(motor
1001 2 1
(motor
revolutions) Fixed = 1
CI 608Fh 01h ... 02h uint32 rw
1
Name of the parameter
2
Parameter number (PNU)
3
Subindices of the parameter for FHPP with DPV0
ć :
The object has no subindex (simple variable)
1 ... 30: The object has subindices from 1 ... 30
4
Subindices of the parameter for FHPP with DPV1
5
Variable type of element. If there is a subindex, this parameter relates to an array,
records are not used
6
Description of the parameter
7
If applicable: Explanation of the subindices
8
Read/write permission: r = read only
w = write only
rw = read and write
9
Corresponding CI object (see section B.4)
Fig. B/3: Representation of the parameter entries
