5. Commissioning
5−49
Festo P.BE−GDCP−SFC−LACI−PB−E N en 0812NH
0. Safeguard device control
Step/
D
i ti
Control bytes Status bytes
Description
Byte B7 B6 B5 B4 B3 B2 B1 B0 Byte B7 B6 B5 B4 B3 B2 B1 B0
0.1 Device control Byte 1 OPM2 OPM1 LOCK ć RESET BRAKE STOP ENABL Byte 1 OPM2 OPM1 HMI 24VL FAULT WARN OPEN ENABL 0.1 Device control
HMI = on
CCON 0 0 0 0 0 0 0 0 SCON 0 0 1 1 0 0 0 0
Byte 2 ć CLEAR TEACH JOGN JOGP HOM START HALT Byte 2 REF STILL DEV MOV TEACH MC ACK HALT
CPOS x 0 0 0 0 0 0 0 SPOS 0 0 0 0 0 1 0 0
0: 0−signal
1: 1−signal
x: not relevant (optional)
F: Edge positive
Tab. 5/6: Control and status bytes Device control active"
Description of 0. Safeguard device control
0.1 Device control via the parametrizing interface
(controlĂpanel or FCT) is activated.
For controlling the SFC−LACI via the control interface,
this device control must first be deactivated via the
parameterizing interface (HMI = off ).
