6. Diagnosis and fault display
6−4
Festo P.BE−GDCP−SFC−LACI−PB−E N en 0812NH
Overview organised according to the type of access to the
diagnostic information
Access Brief description Advantages/
features Detailed
description
LEDs The LEDs indicate the readiness to
operate, positioning status, errors
and bus status. Fast on−the−spot"
recognition of
errors Section 6.2
Control panel of an
SFC−LACI−...−H2 On the LCD display:
Messages, warnings and errors Fast diagnosis
on−the−spot"
diagnosis Section 6.3
In the [Diagnostic] menu:
Diagnostic data, operating mode,
current positioning record, target and
actual positions, speed as well as
information on communication via
the fieldbus Detailed
diagnosis
on−the−spot"
diagnosis Section 4.3
Festo Configuration
Tool With active device connection:
Ĉ Display of the current positioning
record, target and actual positions
as well as speed.
Ĉ Display of the operating mode,
special outputs and operating
states as well as error messages of
the SFC−LACI.
Ĉ Display of the bus status
Ĉ Display of the diagnostic memory
Detailed
diagnosis during
commissioning Help for PlugIn
SFC−LACI
Diagnosing the
PROFIBUS−DP Ĉ Standard diagnosis
Ĉ Device−related diagnosis
Ĉ Diagnosis via FHPP status bytes
SCON and SPOS
Simple diagnosis
via the field bus Section 6.5
PROFIBUS via FPC Ĉ Expanded access to diagnostic
data, e.g.Ădiagnostic memory
Detailed diagnosis
via the field bus Sections 6.4
and 6.6
Tab. 6/2: Diagnostic information as per access
