1. System summary
1−22
Festo P.BE−GDCP−SFC−LACI−PB−EN en 0812NH
1.3 Commissioning options
You can parameterise and commission the SFC−LACI as
follows:
ć with the Festo Configuration Tool (FCT),
} section 5.3
ć at the control panel (HMI, only type SFC−LACI−...−H2),
} chapters 4 and 5
ć via PROFIBUS (PB),
} section 5.4
Functions HMI FCT PB
Parameterisation Ĉ Drive and associated parameters
Ĉ Uploading/downloading of configuration data
Ĉ Saving different configurations in projects
Ĉ Positioning table
Ĉ Switching to next record
Ĉ Force mode
Ĉ Jog mode
Ĉ Brake / clamping unit x
ć
ć
x
ć
ć
ć
ć x
x
x
x
x
x
x
x x
x
x
x
x
x
x
x
Commissioning Ĉ Homing
Ĉ Teaching of positions
Ĉ Testing position sets
Ĉ Testing set chaining
Ĉ Testing force mode
Ĉ Testing jog mode
Ĉ Testing continuous setpoint specification (x)
x
x
ć
ć
ć
ć
x
x
x
x
x
x
ć x
x
x
x
x
x
x
Diagnostics /
Service Ĉ Reading and displaying diagnostic data
Ĉ Oscilloscope function (trace): Graphic presentation of
positioning procedures
x
ć x
x x
ć
Parametrisation can also be done via the parametrisation
interface using the objects of Command Interpreter"
(
}Ăsection B.2). Only experienced users may operate the
module by means of CI commands.
