AT-9108, AT-8518, AT-8525, and AT-8550 User’s Guide
3-11
Port Mirroring
Commands
Port mirroring commands are described in Table 3-6 .
Port Mirroring
Example
The following example selects port 3 as the mirror port, and sends all
traffic coming into or out of the switch on port 1 to the mirror port:
enable mirroring port 3
config mirroring add port 1
The following example sends all traffic coming into or out of the
switch on port 1 and the VLAN default to the mirror port:
config mirroring add port 1 vlan default
Table 3-6 Port Mirroring Configuration Command
Command Description
enable mirroring to Dedicates a port to be the mirror output port.
config mirroring add [mac |
vlan | port | vlan
port ] Adds a single mirroring filter definition. Up to
eight mirroring definitions can be added. You
can mirror traffic from a MAC address, a VLAN, a
physical port, or a specific VLAN/port
combination.
config mirroring delete [mac
| vlan | port
| vlan port | all} Deletes a particular mirroring filter definition, or
all mirroring filter definitions.
disable mirroring Disables port-mirroring.
show mirroring Displays the port-mirroring configuration.
