AT-9108, AT-8518, AT-8525, and AT-8550 User’s Guide
2-27
❑ Community strings — The community strings allow a simple
method of authentication between the switch and the remote
Network Manager. There are two types of community strings
on the switch. Read community strings provide read-only
access to the switch. The default read-only community string
is public. Read-write community strings provide read and
write access to the switch. The default read-write community
string is private. A total of eight community strings can be
configured on the switch. The community string for all
authorized trap receivers must be configured on the switch for
the trap receiver to receive switch-generated traps. SNMP
community strings can contain up to 126 characters.
❑ System contact (optional) — The system contact is a text field
that enables you to enter the name of the person(s)
responsible for managing the switch.
❑ System name — The system name is the name that you have
assigned to this switch. The default name is the model name
of the switch (for example, Summit1).
❑ System location (optional) — Using the system location field,
you can enter an optional location for this switch.
describes SNMP configuration commands.
Table 2-9 SNMP Configuration Commands
Command
Description
enable snmp access
Turns on SNMP support for the switch.
enable snmp traps
Turns on SNMP trap support.
config snmp add
Adds the IP address of an SNMP management
station to the access list. Up to 32 addresses can be
specified.
config snmp add trapreceiver
Adds the IP address of a specified trap receiver. The
IP address can be a unicast, multicast, or broadcast.
A maximum of six trap receivers is allowed.
config snmp community [readonly |
readwrite]
Adds an SNMP read or read/write community string.
The default
readonly
community string is
public
. The default
readwrite
community
string is
private
. Each community string can have
a maximum of 126 characters, and can be enclosed
by double quotation marks.
