Chapter 7: Working with Line Cards and Other Modules
86
Displaying AT-CV5M01 CPM Card Status Information
The following procedure allows you to view and change the parameter
settings on the AT-CV5M01 CPM card.
To display the status of a CPM card, perform the following procedure:
1. From the Main Menu, select Module Status and Configuration.
The Module Status and Configuration Menu, shown in Figure 31 on
page 75, is displayed.
2. Select the CPM card you want to view the status.
3. Press .
The Module Configuration Menu, shown in Figure 38, is displayed.
Figure 38. Module Configuration Menu (CPM Card)
The Module Configuration Menu items and options are described
below:
Module
Displays the type of line card you selected.
Port
Identifies the port of the module selected.
Link
Displays the status of the link state on the ports.
Online - Indicates that there is a valid link.
Offline - Indicates that there is no link.
Module Configuration Menu
Converteon
Module 1
Module: AT-CV5M01
Port Link Speed Mode
A(100BaseTx) Online Auto Auto
Module Name
Reset CPM and Restart System Software
Return to Module Status and Configuration Menu...
