AT-S79 Management Software User’s Guide
Section I: Using the Menus Interface 85
Creating a Static Multicast Address
The procedures in this section describe how to create, delete, and modify
static multicast addresses. See the following procedures:
ˆ “Adding a Static Multicast Address” on page 85
ˆ “Deleting a Static Group” on page 86
ˆ “Deleting a Static Member Port” on page 87
Adding a Static
Multicast
Address
To assign a static multicast address or to assign a group number to an
existing group MAC address, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 16 on
page 70.
2. From the Advanced Switch Configuration Menu, type A to select Static
Multicast Address Configuration.
The Static Multicast Address Table Menu is shown in Figure 20.
Figure 20. Static Multicast Address Table Menu
3. Type A to select Add Static Member Port.
Advanced Switch Configuration -> Static Multicast Address Table Menu
Group MAC Address Group Members
----------------- --------------------------------------------
01:00:5E:00:01:00 1
01:00:5E:00:01:01 2
01:00:5E:00:01:02 3, 4,5,6
01:00:5E:00:01:03 7, 8, 9, 10, 11, 12, 13, 14, 15, 16, 17, 18
01:00:5E:00:01:04 19, 20
01:00:5E:00:01:05 21
01:00:5E:00:01:06 22
-------------------------------------------------------------
[N}ext Page
[A]dd Static Member Port Delete Static [G]roup
[P]revious Page [D]elete Static Member Port [Q]uit to previous menu
Command>
