AT-S79 Management Software User’s Guide
Section I: Using the Menus Interface 179
Configuring Bandwidth Control
The procedures in this section describe how to set bandwidth control
options on the switch and on the ports. See the following sections:
ˆ “Assigning Broadcast or Multicast Packets” on page 179
ˆ “Setting the Ingress Limit Rate” on page 180
ˆ “Setting Ingress Status” on page 180
ˆ “Setting Ingress DLF Status” on page 181
Assigning
Broadcast or
Multicast Packets
To assign broadcast or multicast packets to a port, perform the following
procedure:
1. From the Main Menu, type B to select Basic Switch Configuration.
2. From the Basic Switch Configuration Menu, type B to select
Bandwidth Control.
The Bandwidth Control Configuration Menu is shown in Figure 44.
Figure 44. Bandwidth Control Switch Configuration Menu
Basic Switch Configuration -> Bandwidth Control Configuration Menu
Broad/Multicast Packet Threshold:Low DLF Ingress Packet Status: Enabled
Port Ingress Mode
---- --------- ------------
1 Disabled Bcast/Mcast
2 Disabled Bcast/Mcast
3 Disabled Bcast/Mcast
4 Disabled Bcast/Mcast
5 Disabled Bcast/Mcast
6 Disabled Bcast/Mcast
7 Disabled Bcast/Mcast
8 Disabled Bcast/Mcast
9 Disabled Bcast/Mcast
10 Disabled Bcast/Mcast
11 Disabled Bcast/Mcast
12 Disabled Bcast/Mcast
--------------------------------------------------------------
[N]ext Page
Set Ingress [M]ode [Q]uit to previous menu
[P]revious Page Set Ingress [L]imit Rate
Set [I]ngress Set Ingress [D]LF Status
Command>
