AT-S79 Management Software User’s Guide
Section I: Using the Menus Interface 163
Enabling or Disabling RSTP
To enable or disable RSTP, perform the following procedure:
1. From the Main Menu, type B to select Basic Switch Configuration.
The Basic Switch Configuration Menu is shown in Figure 4 on page 34.
2. From the Basic Switch Configuration Menu, type S to select Rapid
Spanning Tree Configuration.
The Rapid Spanning Tree Configuration Menu is shown in Figure 40.
Figure 40. RSTP Configuration Menu
The RSTP menu allows you to configure RSTP as well as to view the
current settings and contains the following items of information in the
middle portion:
Root Port
The active port on the switch that is communicating with the root
bridge. If the switch is the root bridge for the LAN, then there is no root
port and the root port parameter will be 0.
AT-GS950/16 Local Management System
Basic Switch Configuration -> Rapid Spanning Tree Configuration Menu
Global RSTP Status: Disabled Protocol Version: RSTP
Root Port: 0 Time Since Topology Change: 118 Sec.
Root Path Cost: 0 Topology Change Count: 1
Designated Root: 8000 00C08F1211BB Bridge ID: 8000 010203AABB04
Hello Time: 2 Sec. Bridge Hello Time: 2 Sec.
Maximum Age: 20 Sec. Bridge Maximum Age: 20 Sec.
Forward Delay: 15 Sec. Bridge Forward Delay: 15 Sec.
----------------------- -----------------------------
[E]nable/Disable Global RSTP
Set Bridge [F]orward Delay
Set RSTP Protocol [V]ersion RSTP [B]asic Port Configuration
Set Bridge [P]riority RSTP [A]dvanced Port Configuration
Set Bridge [H]ello Time Topology [I]nformation
Set Bridge [M]aximum Age [Q]uit to previous menu
Command>
