AT-S79 Management Software User’s Guide
Section I: Using the Menus Interface 73
Modifying a Port Trunk
This procedure adds and removes ports from a port trunk.
Caution
Before modifying a trunk, disconnect the cables from the ports of the
trunk. Adding or removing ports from a trunk without first
disconnecting the cables can create loops in your network topology,
which can cause poor network performance and broadcast storms.
To add or remove ports from a trunk, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 16 on
page 70.
2. From the Advanced Switch Configuration Menu, type T to select Trunk
Configuration.
The Trunk Configuration Menu is shown in Figure 17 on page 71.
3. To add ports to a port trunk, type A to select Add Trunk Member. To
remove ports, type R to select Remove Trunk Member.
The following prompt is displayed:
Enter trunk group number>
4. Type the number of the trunk group you want to modify and press
Enter.
The following prompt is displayed:
Enter port members (up to 8 ports) for trunk >
5. Type the ports you want to add or remove from the trunk and press
Enter.
You can specify the ports individually separated by commas (for
example, 1,2,5), as a range of ports separated by a hyphen (for
example, 2-4), or both (for example, 4,6,11-14).
6. Type Q to select Quit to previous menu and save your changes.
7. Modify the port trunk on the other switch and reconnect the cables.
