AT-S79 Management Software User’s Guide
Section I: Using the Menus Interface 107
Creating a VLAN
This section contains the procedure for creating a new port-based or
tagged VLAN. This procedure assigns the VLAN a name, a VID number,
and the untagged and tagged member ports.
After you have performed this procedure, you must configure the untagged
ports of the VLAN by adjusting their PVID values to match the virtual
LAN’s VID number. The PVID value of a port must match its virtual LAN’s
VID in order for a port to be considered an untagged member of the VLAN.
This procedure is found in “Configuring the PVID of Untagged Ports” on
page 111.
To create a VLAN, perform the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 16 on
page 70.
2. From the Advanced Switch Configuration Menu, type V to select VLAN
Management.
The VLAN Management Menu is shown in Figure 23.
Figure 23. VLAN Management Menu
Advanced Switch Configuration -> VLAN Management Menu
Port VLAN Type:
Port 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
-----------------------------------------------------------------------
802.1Q * * * * * * * * * * * * * * * * * * * * * * * *
Port-Based
----------------------- ------------------------------------
802.10 [V]LAN
[C]hange Port VLAN Type
[P]ort-Based VLAN [Q]uit to Previous Menu
Command>
