Chapter 10: Virtual LANs

108

Section I: Using the Menus Interface

3. Type V to select 802.1Q VLAN.

The Tagged-based VLAN configuration Menu is shown in Figure 24.

Figure 24. Tagged-based VLAN Configuration Menu

4. Type C to select Create VLAN.

The VLAN Creation Menu is shown in Figure 24.

5. From the VLAN Management Menu, type C to select Create VLAN.

VLAN Management Menu -> Tagged-based VLAN configuration

VLAN ID

VLAN Name

VLAN Type

-------

-------------------------------

---------

1

Default VLAN

Permanent

2

Sales

Static

----------------------- ------------------------------------
[N]ext Page

[C]reate VLAN

C[o]nfig VLAN Member

[P]revious Page

[D]elete VLAN

[S]et Port Config

[R]eset VLAN to Default

[Q]uit to Previous Menu

Command>
