Chapter 25: Static Multicast Address Table
262 Section II: Using the Web Browser Interface
Configuring Static Multicast Address Table
This procedure explains how to add group MAC addresses to the Static
Multicast Address Table.
To configure the Static Multicast Address Table, perform the following
procedure:
1. From the bookmarks on the left side of the page, select Bridge.
The Spanning Tree folder opens.
2. From the Spanning Tree folder, select Static Multicast.
The Static Multicast Address Table Page is shown in Figure 71.
Figure 71. Static Multicast Address Table Page
3. To add a group MAC address to the Static Multicast Address Table
Page, enter a MAC address in the format xx:xx:xx:xx:xx:xx.
Enter a value between 01:00:5E:00:01 to 01:00:5E:7F:FF:FF.
Note
Use the Tab key to advance from one MAC address segment to the
next.
4. To set the group member of the group MAC address, click a number
next to the Group Member field. Then press Add.
The Static Multicast Address Table is updated with the new
information. See Figure 72 on page 263 for an example.
