AT-S79 Management Software User’s Guide
Section I: Using the Menus Interface 169
Configuring RSTP Port Settings
This section contains the following topics:
ˆ “Configuring the Basic RSTP Port Settings,” next
ˆ “Configuring the Advanced RSTP Port Settings” on page 171
Configuring the
Basic RSTP Port
Settings
To configure the basic RSTP port settings, perform the following
procedure:
1. From the Main Menu, type B to select Basic Switch Configuration.
The Basic Switch Configuration Menu is shown in Figure 4 on page 34.
2. From the Basic Switch Configuration Menu, type S to select Rapid
Spanning Tree Configuration.
The Rapid Spanning Tree Configuration Menu is shown in Figure 40
on page 163.
3. From the Rapid Spanning Tree Configuration Menu, type B to select
RSTP Basic Port Configuration.
The RSTP Basic Port Configuration menu is shown in Figure 41.
Figure 41. RSTP Basic Port Configuration Menu
AT-GS950/16 Local Management System
Rapid Spanning Tree Configuration -> RSTP Basic Port Configuration
Port Trunk Link State Role Priority Path Cost STP Status
---- ----- ---- ---------- --------- ---------------------------
1 --- Up Forwarding Disabled 128 200000 Disabled
2 --- Down Forwarding Disabled 128 200000 Enabled
3 --- Up Forwarding Root 128 200000 Enabled
4 --- Down Forwarding Disabled 128 200000 Enabled
5 --- Down Forwarding Disabled 128 200000 Enabled
6 --- Down Forwarding Disabled 128 200000 Enabled
7 --- Down Forwarding Disabled 128 200000 Enabled
8 --- Down Forwarding Disabled 128 200000 Enabled
9 --- Down Forwarding Disabled 128 20000 Enabled
10 --- Down Forwarding Disabled 128 20000 Enabled
11 --- Down Forwarding Disabled 128 20000 Enabled
12 --- Down Forwarding Disabled 128 20000 Enabled
----------------------------- ---------------------------------
[N]ext Page
Set Path [C]ost
[P]revious Page Set Port STP [S]tatus
Set Port Pr[i]ority [Q]uit to previous menu
Command>
