CH. 16 MAN0878-04-EN

August 12, 2009

Page 88 of 100

ECN # 979

3. Make/Create Clone option enables user to duplicate / Clone application file, all unit settings and all

Selecting Make Clone brings up the screen below for the user:

XLt:

XLe:

Figure 16-3 – Clone Unit Confirm Screen

After confirmation, the OCS will create two new files in the root directory of the Removable Media Drive
as shown below:

AUTOLOAD.PGM Application

file

CLONE.DAT

File having all unit settings and register values from Battery Backed RAM

XLt:

XLe:

Figure 16-4 – Clone Unit Files

NOTE: Make/Create clone operation automatically includes the security in \AUTOLOAD.PGM file for
security enabled files.

4. Once the cloning is successful, OCS gives a message as below:

XLt:

XLe:
