CHAPTER 16: CLONE UNIT
16.1 Overview
‘Clone Unit’ feature allows the user to “clone” the OCS of the exact same model. This feature “clones”
application program and unit settings stored in Battery backed RAM of an OCS into the RM (refer
Removable Media
for details on using RM). It can then be used to clone a different OCS (exact
same model).
This feature can be used for:
• Replacing an OCS by another unit of the same model.
• Duplicating or “clone” units without a PC.
16.2 Clone
User needs to perform the following to Clone:
1. The ‘Clone Unit’ can be accessed by going to the ‘System Menu’ of the OCS. A new menu “Clone
Unit” has been added at the end of the main system menu as shown below:
XLt:
XLe:
Figure 16-1 – System Menu
2. Selecting “Clone Unit” menu will open the following menu screen:
XLt:
XLe:
Figure 16-2 – Clone Unit Menu before Cloning
Note:
a. In the above Figure16-2, F3 and F4 are inactive in Clone Unit.
b. DSK – when selected shows number of total and free bytes in Removable Media.
