MAN0878-04-EN CH. 11
August 12, 2009 Page 53 of 100 ECN # 979
A Sub-Menu generally shows a list of System Settings and their values. After opening a Sub-Menu, if any
of its System Settings are editable, the first System Setting that can be edited is highlighted. If desired,
the
↓ and ↑ keys can be used to select a different System Setting to be edited.
At this point, either press ESC to exit the Sub-Menu (returning to the Main Menu) or press Enter to edit
the highlighted System Setting. If Enter is pressed, the System Setting’s value will be highlighted,
indicating that it is ready to be modified.
When modifying a System Setting’s value, use either the arrow keys (
← → ↓ ↑ ) or the numeric keys, or the
appropriate touch screen icons to select a new value.
The arrow keys are used to edit System Settings that have just a few possible values. Each time the
arrow key is pressed, a new possible value is displayed. When the desired value appears, press the
Enter key to save it; otherwise press the ESC key to cancel the edit.
The numeric keys are normally used to enter numeric System Settings. In addition, to edit a single
numeric digit, use the
← or → key to select the digit and then either press a numeric key or use ↓ or ↑ to
modify the digit. In any case, after entering the new desired value, press the Enter key to save it;
otherwise press the ESC key to cancel the edit.
11.3
System Menu – Details
The following sections describe each of the Sub-Menus in detail.
Set Network ID
The Network ID Sub-Menu only appears for XLe/XLt models that have CAN ports (XE1xx). This Sub-
Menu displays two System Settings of which only Network ID is editable.
Network Ok? Yes = NET1 connected to a CAN network and functioning properly
No = Not ready to communicate on CAN network
Network ID:
1 to 253 = This node’s CsCAN Network ID; must be unique on network
Set Network Baud
The Network Baud Sub-Menu only appears for XLe/XLt models that have CAN ports (XE1xx). This Sub-
Menu displays just one System Setting and it is editable.
Network Baud? 125 KB = 125 KBaud CAN network
250 KB = 250 KBaud CAN network
500 KB = 500 KBaud CAN network
1 MB = 1 MBaud CAN network
Set Contrast
The Set Contrast Sub-Menu displays just one System Setting and it is editable.
Contrast: = Current display contrast setting
