HE-XT102-10

Specifications / Installation

A







1 Specifications

HE-XT102 Specifications

Digital DC Inputs

Inputs per Module

12 including 4 configurable

HSC inputs

Commons per Module

1

Input Voltage Range

12 VDC / 24 VDC

Absolute Max. Voltage

35 VDC Max.

Input Impedance

10 k

Input Current

Positive Logic Negative

Logic

Upper Threshold

0.8 mA

-1.6 mA

Lower Threshold

0.3 mA

-2.1 mA

Max Upper Threshold

8 VDC

Min Lower Threshold

3 VDC

OFF to ON Response

1 ms

ON to OFF Response

1 ms

HSC Max. Switching Rate

10 kHz Totalizer/Pulse, Edges
5 kHz Frequency/Pulse, Width

2.5 kHz Quadrature

Digital Relay Outputs

Outputs per Module

6 relay

Commons per Module

6

Max. Output Current per Relay

3 A at 250 VAC, resistive

Max. Total Output Current

5 A continuous

Max. Output Voltage

275 VAC , 30 VDC

Max. Switched Power

1250 VA, 150 W

Contact Isolation to XLE

ground

1000 VAC

Max. Voltage Drop at Rated

Current

0.5 V

Expected Life

(See Derating section for

chart.)

No load: 5,000,000

Rated load: 100,000

Max. Switching Rate

300 CPM at no load

20 CPM at rated load

Type Mechanical

Contact

Response Time

One update per ladder scan

plus 10 ms

Analog Inputs, Medium Resolution

Number of Channels

2

Input Ranges

0 - 10 VDC

0 – 20 mA

4 – 20 mA

Safe input voltage range

-0.5 V to +12V

Input Impedance

(Clamped @ -0.5 VDC to 12

VDC)

Current

Mode:
100

Voltage Mode:

500 k

Nominal Resolution

10 Bits

%AI full scale

32,000 counts

Max. Over-Current

35 mA

Conversion Speed

All channels converted once per

ladder scan

Max. Error at 25

°C

(excluding zero)

*can be made tighter (~0.25%)

by adjusting the digital filter

setting to 3.

4-20 mA 1.00%
0-20 mA 1.00%

0-10 VDC 1.50%*

Additional error for

temperatures other than 25

°C

TBD

Filtering

160 Hz hash (noise) filter

1-128 scan digital running

average filter

Clock Accuracy

+/- One Minute/Month at 20C









Thermistor Inputs, Medium Resolution

Number of

Channels

2

Input Ranges

Input Impedance

(Clamped @ -0.5

VDC to 12 VDC)

10K OHMThermistor

Half Bridge

9.59K ohm pulled up to

4.8 VDC

Nominal Resolution

%AI at 10K Ohm

10 Bits

15,008 counts

Conversion Speed

All channels converted once per ladder scan

Max. Error at 25

°C

reading / ambient

±0.5°F or ±0.3°C

Using specified linearization

in ladder program

Additional error for

reading / ambient

temperatures other

than 25

°C

TBD

Filtering

160 Hz hash (noise) filter

1-128 scan digital running average filter

General Specifications

Required Power

(Steady State)

150 mA @ 24 VDC

Required Power

(Inrush)

30 A for 1 ms @ 24 VDC

Primary Power

Range

10 – 30 VDC

Relative Humidity

5 to 95% Non-condensing

Operating

Temperature

-10

°C to +60°C

Terminal Type

Screw Type, 5 mm Removable

Weight

12 oz. (340.19 g)

CE

UL

See Compliance Table at

http://www.heapg.com/Support/compliance.htm



2 Safety





























XLT OCS Model: HE-XT102-10

12 Digital DC Inputs

2 10k Thermistors , 2 Analog Inputs (Medium Resolution)

6 Digital Relay Outputs

Want More Information?

To download the XLT User

Manual (

MAN0863

), refer to

Technical Support

in this

document.

Warning:

Consult

user documentation.

Warning:

Electrical

Shock Hazard.

When found on the product, the following symbols specify:


WARNING:

To avoid the risk of electric shock or burns,

always connect the safety (or earth) ground before making
any other connections.
WARNING:

To reduce the risk of fire, electrical shock, or

physical injury it is strongly recommended to fuse the voltage
measurement inputs. Be sure to locate fuses as close to the
source as possible.
WARNING:

Replace fuse with the same type and rating to

provide protection against risk of fire and shock hazards.
WARNING:

In the event of repeated failure, do not replace

the fuse again as a repeated failure indicates a defective
condition that will not clear by replacing the fuse.
WARNING:

Only qualified electrical personnel familiar with

the construction and operation of this equipment and the
hazards involved should install, adjust, operate, or service this
equipment. Read and understand this manual and other
applicable manuals in their entirety before proceeding.
Failure to observe this precaution could result in severe bodily
injury or loss of life.

Note: The highest usable frequency is 65 KHz for the PWM output
