View Status
The View Status Sub-Menu displays up to 17 System Settings. The Lcl Net Use % and All Net Use %
System Settings only appear for XLe/XLt models that have CAN ports (XE1xx). Only the Mode System
Setting is editable.
Model: XExyyz = 5 or 6 character Model number of this XLe/XLt unit
x is 1 for models that have a CAN port; 0 = no CAN port
yy indicates the installed I/O module; 00 = no I/O module
z indicates the installed COM module; N = no COM module
Mode:
Idle = XLe/XLt is in Idle mode
DoIo = XLe/XLt is in Do I/O mode
Run = XLe/XLt is in Run mode
Scan Rate(mS):
0.0 = XLe/XLt is not in Run mode
0.1 to 999.9 = Average number of mS for each ladder scan
Lcl Net Use %:
0.0 to 100.0 = CAN network bandwidth % used by this XLe/XLt node
All Net Use %:
0.0 to 100.0 = CAN network bandwidth % used by all nodes
Ladder Size:
x = Number of bytes in application ladder program
Config Size:
x = Number of bytes in application I/O configuration
Graphics Sz:
x = Number of bytes in application graphic screens
String Size:
x = Number of bytes in application string table
Bitmap Size:
x = Number of bytes in application bitmaps
Text Size:
x = Number of bytes in application text tables
Font Size:
x = Number of bytes in application font tables
Protocol Sz:
x = Number of bytes in application downloaded protocols
SMS Msg Sz:
x = Number of bytes in application SMS protocol configuration
Firmware Rev:
xx.yy = Current firmware version
CPLD Rev:
x.y = Current CPLD (Complex Programmable Logic Device) version
Self-Test:
Ok = All power-on self-tests passed
Fault = One or more power-on self-tests failed
View Diags
The View Diags Sub-Menu displays up to 14 System Diagnostics, all of which are not editable. The Net
Errors, Network State, Network ID and Dup Net ID System Diagnostics only appear for XLe/XLt models
that have CAN ports (XE1xx).
