Removable Media
XLe Specific:
The Removable Media Sub-Menu displays the Removable Media Manager (see CHAPTER 8). After
selecting Removable Media from the Main Menu, one of four Sub-Menu screens will appear:
If the Removable Media Manager displays files or directories, as in the last example above, there are
several options available:
If
→ is pressed, the number of total and free bytes is displayed. Then, pressing ← returns to the normal
file and directory display.
If a soft key (on either side of the display) is pressed, a pop-up window appears on the right side of the
display, showing the function key options as follows:
F1 Delete = Delete the highlighted file or directory
F2 DelAll = Delete all files and directories
F3 Format = Format the Micro SD card
F4 SavPgm = Save XLe/XLt application to DEFAULT.PGM
Esc Cancel = Cancel current operation (back up one screen)
Pressing the soft key again or pressing ESC returns to the normal file and directory display.
Shows up to five files or directory names at a time
Media Directory
No Card
Media Directory
Dir Empty
Media Directory
Initializing
= No Micro SD card has been installed in the Memory slot
= Micro SD card is installed, but it is still initializing
= Micro SD card is installed and initialized, but contains no files
Scrollbar only appears if displayed directory contains more than five files
and/or directories.
Shows size of highlighted file or shows
Media Directory
FILENAM1.EXT
U 11.7K
FILENAM2.EXT 10-20
FILENAM3.EXT
-05
FILENAM4.EXT 1:09p
FILENAM5.EXT
V FreeZ
= Micro SD card is installed and initialized, and it contains files
