Specifications

HE-XE102 Specifications

Digital DC Inputs

Inputs per Module

12 including 4 configurable HSC inputs

Commons per Module

1

Input Voltage Range

12 VDC / 24 VDC

Absolute Max. Voltage

35 VDC Max.

Input Impedance

10 k

Input Current

Positive Logic

Negative Logic

Upper Threshold

0.8 mA

-1.6 mA

Lower Threshold

0.3 mA

-2.1 mA

Max Upper Threshold

8 VDC

Min Lower Threshold

3 VDC

OFF to ON Response

1 ms

ON to OFF Response

1 ms

HSC Max. Switching Rate

10 kHz Totalizer/Pulse, Edges
5 kHz Frequency/Pulse, Width

2.5 kHz Quadrature

Digital Relay Outputs

Outputs per Module

6 relay

Commons per Module

6

Max. Output Current per Relay

3 A at 250 VAC, resistive

Max. Total Output Current

5 A continuous

Max. Output Voltage

275 VAC , 30 VDC

Max. Switched Power

1250 VA, 150 W

Contact Isolation to XLE ground

1000 VAC

Max. Voltage Drop at Rated

Current

0.5 V

Expected Life

(See Derating section for chart.)

No load: 5,000,000

Rated load: 100,000

Max. Switching Rate

300 CPM at no load

20 CPM at rated load

Type

Mechanical Contact

Response Time

One update per ladder scan plus 10

ms

Analog Inputs, Medium Resolution

Number of Channels

2

Input Ranges

0 - 10 VDC,

0 – 20 mA, 4 – 20 mA

Safe input voltage range

-0.5 V to +12V

Input Impedance
(Clamped @ -0.5 VDC to 12VDC)

Current Mode
100

Voltage Mode

500 k

Nominal Resolution

10 Bits

%AI full scale

32,000 counts

Max. Over-Current

35 mA

Conversion Speed

All channels converted once per

ladder scan

Max. Error at 25

°

C

(excluding zero)

*can be made tighter (~0.25%) by

adjusting the digital filter setting to 3.

4-20 mA 1.00%
0-20 mA 1.00%

0-10 VDC 1.50%*

Additional error for temperatures

other than 25

o

C

TBD

Filtering

160 Hz hash (noise) filter

1-128 scan digital running average filter

Temperature/Pressure Sensor

ES2T – 250/300

ESP-100

Channel

1

2

Range

5

°

F - 300

°

F

0-100 PSIG

Input Im

2.49 K ohms

249 ohms

Nominal Res

10 bits

Nominal %AI = 15000

2.49K ohms

249 ohms

Conversion Speed

All channels converted once per scan

Typical Error Including Linearization

2

°

F

1 PSIG

Additional error for reading /

ambient temperatures other than

25

o

C

TBD

Filtering

160 Hz has (noise filter)

1-128 scan digital running average filter

General Specifications

Required Power(Steady State)

130 mA @ 24 VDC

Required Power (Inrush)

30 A for 1 ms @ 24 VDC

Primary Power Range

10 – 30 VDC

Relative Humidity

5 to 95% Non-condensing

Operating Temperature

0

°

C to +50

°

C










General Specifications

Terminal Type

Screw Type, 5 mm Removable

Weight

12 oz. (340.19 g)

CE

UL

See Compliance Table at

http://www.heapg.com/Pages/TechSupport/ProductCert.html

Clock Accuracy

+/- 7 Minute/Month at 20

o

C

Highest usable frequency for PWM output is 65 KHz



2

Panel Cut-Out and Dimensions


Note: Max. panel thickness: 5 mm.

Refer to XLE User Manual (MAN0805) for panel box information and a handy checklist of
requirements.
Note: The tolerance to meet NEMA standards is

±

0.005” (0.1 mm).















3

Ports / Connectors / Cables


Note: The case of the XLE is black, but for clarity, it is shown in a lighter gray color.


















XLE OCS Model: HE-XE102-62

12 Digital DC Inputs

ES2T-250/300 Temperature Sensor, ESP-100 Pressure Sensor, 2 Analog Inputs (Medium Resolution)

6 Digital Relay Outputs

3

.6

2

2

[

9

2

m

m

]

3.622 [92mm]

001XLE002

To Remove Back Cover:
Unscrew 4 screws located on the back of the unit. Lift lid.

Power Connector


Power Up:
Connect to Earth Ground.
Apply 10 - 30 VDC.
Screen lights up.

CAN Connector

Use the CAN Connector
when using CsCAN network.

CAUTION: Do not over
tighten screws when
screwing the lid back on.

MJ1

(RS-232 / RS-485)

MJ2

(RS-232 / RS-485)

J1

I/O

Jumper

Memory Slot

001XLE029-R2

J2

I/O

Jumper

NET 1

(CsCAN)

Power

DIP

Switch

I/O Jumpers: (Not Shown):
I/O Jumpers (JP) are located
internally. To access, remove
back cover of unit.


Memory Slot:
Uses Removable Memory
for data logging, screen
captures, program loading
and recipes.
Horner Part No.: HE-MC1

Serial Communications:
MJ1
: (RS-232 / RS-485) Use
for Cscape programming and
Application-Defined
Communications.

MJ2:
(RS-232 / RS-485) Use
for Application-Defined
Communications.


Wiring
Connectors (J1 /
J2):
I/O Jumpers
(JP1 / JP2),
and
External
Jumpers (RS-
485)
are
described in the
Wiring and
Jumpers
section
of this document.
