NOTE:
You must log in with Administrator or Continuous Access XP Journal write access, and you
must be in Modify mode. If you are in the View mode, you can view the Continuous Access
XP Journal pair status, but you cannot modify the settings.
3.
Click the Continuous Access XP Journal button (
). The Journal Operation pane appears.
4.
On the DKC Operation pane, select Port, and set the initiator and RCU target ports (see
5.
On the DKC Operation pane, select DKC. The Add DKC pane appears.
6.
Set the S/N of the array to be connected, controller ID, path group ID, initiator port in the array,
and RCU target port in the array to be connected (see
Associating primary and remote arrays and
configuring logical paths (Add DKC)
).
7.
On the Add DKC pane, click Option, and set the local array's options (see
and remote arrays and configuring logical paths (Add DKC)
8.
On the Journal Operation pane, specify the journal group number.
9.
On the Edit JNL Volumes pane, register the journal volumes (see
).
10.
On the Paircreate pane of the Pair Operation pane, register the primary and secondary data
volumes and journal groups that are paired (see
Creating a pair of data volumes (Paircreate)
NOTE:
Only the primary array can register Continuous Access XP Journal pairs.
11.
Exit the Continuous Access XP Journal, and disconnect from the array.
12.
Repeat step 3 through step 11 for each array that will function as a Continuous Access XP Journal
primary array. After configuring the primary arrays, adding the secondary arrays, and configuring
the Continuous Access XP Journal options and journal groups, you are ready to begin Continuous
Access XP Journal volume pair operations.
Combining Continuous Access XP Journal with other data
management functions
Some volume types that non-Continuous Access XP Journal functions use can also be used as Continuous
Access XP Journal data volumes and/or journal volumes.
explains whether non-Continuous
Access XP Journal volumes can also be used as Continuous Access XP Journal volumes.
Table 18 Whether non-CA XP Journal volumes can be used as CA XP Journal volumes
Functions and volumes Can volumes be used
as primary data
volumes?
Can volumes be used
as secondary data
volumes?
Can volumes be used
as journal volumes?
Volume Manager
LUSE volume
Yes.
Yes.
No.
Business Copy XP
P-VOL in PSUS status
Yes.
1
Yes.
1
No.
P-VOL in COPY(RS-R)
status
No.
No.
No.
