G-ID: Group number of the host group or iSCSI target to display. To display all host groups

and iSCSI targets, select ALL.

JNL Group: Journal group to be displayed. To display all journal groups, select ALL.

Mirror: Mirror to be displayed. To display all mirrors, select ALL.

P-VOL/S-VOL: Type of volumes to be displayed.
• To display all primary data volumes, select P-VOL.
• To display all secondary data volumes, select S-VOL.
• To display all primary and secondary data volumes, select ALL.

CLPR: CLPR to be displayed. To display all CLPRs, select ALL.

Internal/External VOL: Specifies if internal or external volumes appear in the list.
To display all internal and external volumes, select ALL.

Status: Pair statuses. The volumes with the specified statues are displayed in the list.

Set: Applies settings in the Display Filter pane to the list.

Reset: Restores all options in the Display Filter pane to the default state. All lists display ALL. All

check boxes are selected.

Saving pair status information to a text file

Use the Continuous Access XP Journal snapshot function to save information about pair status in a

text file. This text file is called a snapshot file.

NOTE:

You can use the snapshot function only while client file access is enabled. When client file access is not

enabled, the Snapshot button does not appear on the Pair Operation pane. For more information about

client file access settings, see the

HP StorageWorks Command View XP user guide for XP Disk Arrays

or

the

HP StorageWorks XP Remote Web Console user guide for XP12000/XP10000/SVS200

.

NOTE:

If the number of pairs exceed approximately 10,000, the snapshot function is too large to save on a

floppy disk. If this happens, save the snapshot file on a large-capacity disk.

The following is an example of a snapshot file.


Port Gr(Name) LUN Vol Status JNG Mr S/N(CNTL) Port Gr LUN Vol JNG Type CTG

ErrLv Sync CLPR
CL3-E 00(3E-G00 ) 000 00:00 PAIR 01 02 11111(04) CLG-R FF 1FF 3F:FF F6 P-VOL

09 Group 100 00:CLPR0
CL3-E 00(3E-G00 ) 008 00:08 SMPL 01:CLPR1
CL3-E 00(3E-G00 ) 009 00:09 PSUS 10 02 11111(04) CLG-R FF 1F6 3F:F6 ED P-VOL

12 LU 80 02:CLPR2
(1) (2) (3) (4) (5) (6) (7) (8) (9) (10) (11) (12) (13) (14) (15) (16) (17)

(18)

Continuous Access XP Journal user guide

147
