NOTE:
If you specify the unmounted LU, the graph is not displayed.
NOTE:
When a graph displays, the CU and LDEV numbers appear above the graph. If the logical
volume is an external LU, # appears after the LDEV number. For more information about external
LUs, see the HP StorageWorks External Storage XP user guide .
4. In the Monitor Data box, select the I/O statistics data you want to display on the graph. You must
select at least one box. Table 31 describes I/O statistics data.
5. Click Set. The Usage Operations pane now displays a graph showing the selected I/O statistics
data for the selected LUs.
To enlarge the displayed graph, right-click the graph, and select Large Size. To return the graph to
normal size, right-click the graph, and select Normal Size.
NOTE:
The length of a host group or iSCSI target name in the upper portion of the graph is limited
to a maximum of eight characters when the graph is normal size. To display a full host
group name, enlarge the graph. To find a full iSCSI target name, look at the tree in the Pair
Operation pane. If you enlarge the graph, the length of an iSCSI target name increases
to a maximum of 32 characters.
NOTE:
To stop displaying the usage monitor graph, right-click the graph, and select Close. To stop displaying all
graphs, select Close All. The usage monitor graph automatically closes when you do one of the following:
• Select another tab.
• Select another program product.
• Exit Command View XP or XP Remote Web Console.
• Stop the usage monitoring function by selecting Disable in the Monitoring Switch box, and clicking
Apply.
