Page 52

Table 14 Journal group specifications
Item
Support specifications
Number of journal groups
Up to 256 journal groups (No. 0 - 255) per array if all the following
conditions are satisfied:
•
Array is an XP12000 (not an XP10000).
•
Microprogram version is 50-05-00-00 or later.
•
Shared memory options #3, #4, and #5 are already installed.
•
High Performance mode is applied to shared memories
1
.
NOTE:
Only the HP service engineer can install shared memory options
and apply High Performance mode. If necessary, contact your
HP account support representative.
Up to 16 journal groups (No. 0 - 15) per array if any of these
conditions are not satisfied.
Number of data volumes in a
journal group
Up to 4,096
Number of journal volumes in a
journal group
Up to 16
Number of Mirror IDs
Up to 4 (ID No.: 0 to 3)
NOTE:
If Continuous Access XP Synchronous uses No. 0, No. 1 to No. 3
are available for Continuous Access XP Journal.
1
Only the HP service engineer can install shared memory options and apply High Performance mode. If necessary,
contact your HP account support representative.
The same number of journal volumes is not required in the master and restore journal groups that
are paired.
A mirror ID is required for a configuration that will be supported in the future within a 3-data center
(3DC) configuration. Each pair relationship in a journal group is called a “Mirror.” The Mirror
ID identifies two or more mirrors for one journal group. The same Mirror ID is applied for the
data volume pair. See
Combining Continuous Access XP Journal with Continuous Access XP (3DC
for more information.
• Table 15
describes the relationship between data volumes, journal volumes, and data and journal
volumes in a journal group.
Table 15 Volume specifications in journal groups
Item
Support specification
Emulation type
Journal volumes and data volumes in the same journal group can belong to
different CLPRs. It is recommended journal volumes should belong to the same
CLPR. Also it is recommended data volumes should belong to the same CLPR.
NOTE:
Only OPEN-V can be used for journal volumes.
Volume capacity
Same or different capacity is available.
CLPR
Journal and data volumes in the same journal group must belong to the same CLPR.
NOTE:
A primary journal group and the corresponding secondary journal group
need not belong to the same CLPR.
52
Continuous Access XP Journal operations requirements and restrictions
