NOTE:
The controller ID for an XP12000/XP10000 is 4.
NOTE:
This column can be blank while the pair is in transition to the SMPL status. To display the latest
information in this column, refresh the screen.
• Pair Port-G-ID-LUN: Remote array's data volume.
This column indicates a primary data volume if the remote array is a primary array.
This column indicates a secondary data volume if the remote array is a secondary data volume.
The following is an example of an entry in this column.
Figure 58 Information in Pair Port-G-ID-LUN column in Pair Operation pane
1
Port
2
Group number of the host group or iSCSI target
3
LUN (logical unit number)
4
Logical volume ID
NOTE:
If a logical volume is an external LU, # appears after the LDEV number. For more information
about external LUs, see the
HP StorageWorks External Storage XP user guide
.
Pair Port-G-ID-LUN displays the port ID, G-ID, and LUN of the volume that you specified in the
remote subsystem when creating the pair. If you change or delete the port ID, G-ID, or LUN of the
volume in the remote subsystem, incorrect information will be displayed in Pair Port-G-ID-LUN.
So, unless you have any special circumstances, do not change or delete the port ID, G-ID, or
LUN that you specified when creating the pair.
This column is blank if the volume in the local array is not a primary or secondary data volume.
• Pair JNLG: Remote array's journal group number. This column is blank if the volume in the
local array is not a primary or secondary data volume.
• CTG: Consistency group number. This column is blank if the volume in the local array is
not a primary or secondary data volume.
• Err Lv.: Range of the pair split when an error occurs.
• Group: If an error occurs with this pair, all pairs in the mirror where this pair belongs
are split.
• LU: If an error occurs with this pair, only this pair is split.
• Prog./Sync.: If the volume in the local array is a primary data volume, this column displays
the progress of an initial copy operation.
If the volume in the local array is a secondary data volume, this column displays the following
information:
• If the volume pair is not split, this column displays nothing.
