Basic Switch Management
69 Fabric OS Procedures Version 3.1.x/4.1.x User Guide
The following entries appear:
■ Local Domain - Domain number of local switch.
■ In Ports - Port from which a frame is received.
■ Domain - Destination domain of incoming frame.
■ Out Port - The Port that incoming frame will be forwarded to, in order to
reach the destination domain.
■ Metric - Cost of reaching destination domain.
■ Hops - The maximum number of hops to reach destination domain.
■ Flags -Indicates if route is dynamic (D) or static (S). A dynamic route is
discovered automatically by the FSPF path selection protocol. A static
route is assigned using the command
urouteconfig .
■ Next (Dom, Port) - Domain and port number of the next hop. These are
the domain number and the port.
Example: The example below displays the routing information of all the active
ports:
:
switch:admin> urouteshow
Local Domain ID: 3
In Port Domain Out Port Metric Hops Flags Next (Dom, Port)
--------------------------------------------------------------------------
0 1 11 1000 1 D 1,0
11 2 0 1500 2 D 4,0
4 0 500 1 D 4,0
16 1 27 1000 1 D 1,1
27 2 16 1500 2 D 4,16
4 0 500 1 D 4,0
