Initial Configuration

Example:

Configuring a Logical Switch IP Address for the Core Switch 2/64

1. Have the following information available:

— Ethernet IP Address

— Ethernet Subnetmask

— Fibre Channel IP Address (Optional)

— Fibre Channel Subnetmask

2. Log in to the switch as the admin user.

3. Enter the

ipaddrset

command at the command line. An interactive

session is opened.

4. Choose the logical switch that you want to configure. Enter the value that

corresponds to that logical region:

— Enter 0 to configure logical switch 0 (slot 1 though 4)

— Enter 1 to configure logical switch 1 (slot 7 though 10)

5. Enter the Ethernet IP address when prompted. Click Enter

6. Enter the Ethernet Subnetmask when prompted. Click Enter

7. (Optional) Enter the Fibre Channel IP address. Click Enter

8. Enter the Fibre Channel Subnetmask. Click Enter

9. Enter the

ippaddrshow

command to verify the data you entered, and exit.

10. Repeat

step 1

through

step 9

to configure the second logical switch.

switch:admin> ipaddrset

Switch number [0 for switch0, 1 for switch1, 2 for CP0, 3 for CP1]: 2

Ethernet IP Address [192.168.186.61]:

Ethernet Subnetmask [255.255.255.0]:

Hostname [192.168.68.193]:

Gateway IP [255.255.255.0]:

Committing configuration...Done.

switch:admin>
