Basic Switch Management
53 Fabric OS Procedures Version 3.1.x/4.1.x User Guide
Fabric Configuration Settings
It is important to have consistent system configuration settings since inconsistent
parameters among switches in the same fabric can cause fabric segmentation. To
troubleshoot a fabric segmentation issue, refer to “
Restoring the System
Configuration Settings ” on page 55.
The following parameters are included in the System Configuration Settings:
■ Fabric Parameters
■ Virtual Channel Settings
■ Zoning Operation Parameters
■ Rscn Transmission Mode
■ NS Pre-zoning Mode
■ Arbitrated Loop Parameters
■ System Services
■ Portlog Events Enable
Displaying the Fabric Configuration Settings
To display and check system configuration settings, perform the following
procedure.
1. Log into the switch as the admin user.
2. Enter the configshow command at the command line. The system
configuration settings appear.
switch:admin> configshow
RSCN.end-device.TransmissionMode:0
alpaList:1
boot.device:fei
boot.file:/usr/switch/firmware
boot.gateway.ipa:192.168.147.172
boot.ipa:192.168.147.172:ffffff00
boot.mac:10:00:00:60:69:80:04:22
boot.name:ter172
boot.server.ipa:
