14 N2620A User’s Guide
1 Introducing the FrameScope Pro
Connecting to the Network and Using the FrameScope Pro
Follow these steps to connect the FrameScope Pro to the
network and use it for testing.
1 Connect the cable to the FrameScope Pro network port. If
you want to perform fiber link testing, connect the cable to
the SFP port.
2 Use the front panel touch screen and control buttons to
operate the FrameScope Pro. When testing with the
FrameScope Pro, use the following operating tips:
a Select the items on the screen by pressing them with your
finger, or with a stylus, or by scrolling the highlight bar
using . The screen may not detect a quick press,
therefore you should press firmly.
b Many screens have lists of items that you can navigate
using . Press up or down to scroll through the list of
items.
c Selected items are highlighted in dark blue. Most screens
have a default selected item.
d Execute a selected item by pressing the item itself or
.
3 To return to the Main Menu screen at any time, press Main
Menu
on the bottom of the display.
4 To return to the previous screen, press Back on the bottom of
the display.
