PPH-1503 User Manual
78
Vertical bars are used to separate one or more optional parameters. Only
one command can be selected; With the following two parameters,
{ON|OFF} only ON or OFF can be selected.
3. Square Brackets [ ]
The contents inside square brackets represent keywords or parameters
that can be omitted when executing a command. For example: For the
commands :OUTPut[:STATe] {ON|OFF}, [STATe] can be omitted.
4. Angle Brackets
The parameters in angle brackets must be substituted with a valid
parameter. For example: For the command :DISPlay: CONTrast
, must be use a numerical value instead such
as, :DISPlay:CONTrast 1
Parameter Types
The commands have a number of different parameter categories. How
the parameters are set depend on the parameter categories.
1. Boolean
Commands parameter that have to states “OFF” and “ON”, for example,
DISPlay:FOCUs {ON|OFF}. “ON” will turn on the focus display
function, while “OFF” will turn it off.
2. Consectutive Integers
